加热器功率：单相 220V50Hz, 4.5KW(-5%~+10%)
耐压 1800V/3S,漏电电流<20Ma
加热管外部采用铸铝压铸成型
电源线线长 3 米,外包覆铁氟龙套管

Heater power: single-phase 220V 50Hz, 4.5KW(-5%~+10%)
Withstand voltage 1800V/3S, leakage current<; 20Ma
The exterior of the heating tube is formed by die casting cast aluminum
The power cord is 3 meters long and wrapped in a PTFE sleeve

采用 SUS316L 洁净管盘制成型
进出液口径为 3/8,使用变径卡套接头转换
使用药液流量：1L/min

Made of SUS316L clean tube tray for molding
The inlet and outlet diameter is 3/8, and a variable diameter sleeve connector is used for conversion
Flow rate of medication: 1L/min

采用 SUS304 材质，厚度 2MM 焊接成型，紧固螺丝采用 SUS304 不锈钢螺栓
密封圈采用半氟密封圈

Made of SUS304 material, welded to a thickness of 2MM, with SUS304 stainless steel bolts used for fastening screws
The sealing ring adopts a semi fluorinated sealing ring

采用 SUS304 材质，厚度 2MM 焊接成型，紧固螺丝采用 SUS304 不锈钢螺栓
密封圈采用半氟密封圈

Made of SUS304 material, welded to a thickness of 2MM, with SUS304 stainless steel bolts used for fastening screws
The sealing ring adopts a semi fluorinated sealing ring

1.安装有 K 型热电偶检测加热器主体温度，数量 1 条
2.加热器主体安装有跳跃式温度保护开关，温度 125℃，数量 1 个
3.出液端安装有 K 型热电偶，检测出液温度，数量 1 条
4.加热器主体内部设置有 N2 气进出口，1/4 管螺纹接口，N2 的使用压力 0.05~0.1MPa

1. Install K-type thermocouple to detect the temperature of the heater body, quantity 1
2. The heater body is equipped with a jump type temperature protection switch, with a temperature of 125 ℃ and a quantity of 1
3. There is a K-type thermocouple installed at the liquid outlet to detect the temperature of the liquid, with a quantity of 1
4. The heater body is equipped with N2 gas inlet and outlet, 1/4 pipe threaded interface, and N2 usage pressure of 0.05~0.1MPa

1.产品禁止干烧，必须将温度开关接入控制电路中。
2.产品可靠接地。
3.安装加热器时，请紧固加热器主体上所有卡套接头。

1. Dry burning is prohibited for the product, and the temperature switch must be connected to the control circuit.
2. The product is reliably grounded.
3. When installing the heater, please tighten all the sleeve joints on the heater body.
